Purpose
The Web Application Security Consortium (WASC) is pleased to announce the WASC Web Application Security Statistics Project 2007. This initiative is a collaborative industry wide effort to pool together sanitized website vulnerability data and to gain a better understanding about the web application vulnerability landscape. We ascertain which classes of attacks are the most prevalent regardless of the methodology used to identify them. Industry statistics such as those compiled by Mitre CVE project provide valuable insight into the types of vulnerabilities discovered in open source and commercial applications, this project tries to be the equivalent for custom web applications.
Goals
- Identify the prevalence and probability of different vulnerability classes
- Compare testing methodologies against what types of vulnerabilities
they are likely to identify.
Methodology
The statistics was compiled from web application security assessment projects which were made by the following companies in 2007 (in alphabetic order):
Booz Allen Hamilton
BT
Cenzic with Hailstorm and ClickToSecure
dblogic.it
HP Application Security Center with WebInspect
Positive Technologies with MaxPatrol
Veracode with Veracode Security Review
WhiteHat Security with WhiteHat Sentinel
Identified vulnerabilities for assessment technologies have been aggregated using the Web Security Threat Classification as a baseline.
The statistics includes 2 different data sets: automated testing
results and security assessment results made using black and white
box methodology.
Automated testing results contain data about the scanning of hosting
provider sites without any customizing the settings (with standard
profile). While analyzing this data it is recommended to consider that not every site tested uses interactive elements. Additional customized settings made by an expert would improve
vulnerability detection effectiveness by automated scanners.
It is also recommended to consider automatic scanning type 1 and 2 errors: the scanner might miss the vulnerability or suggest the vulnerability which does not exist. A manual expert assessment allows to eliminate type 2 errors and to
minimize type 1 errors (but not eliminate them).
Black and white box security assessment statistics contain manual
and automatic analysis results. The analysis includes scanning with
preliminary settings followed by manual analysis, manual search for
vulnerabilities which cannot be detected by automated scanner, and
source code analysis.
Consequently 3 data sets were obtained:
- Overall statistics
- Automated scanning statistics
- Black and and white box methods security assessment statistics
The overall statistics includes analysis results of 32,717 sites and
69,476 vulnerabilities of different degrees of severity. The detailed
information can be found in Statistics chapter.
Data analysis
Data analysis shows that more than 7% of analyzed sites can be
compromised automatically. About 7.72% applications had a high
severity vulnerability detected during automated scanning (P. 1).
Detailed manual and automated assessment using white and black box
methods shows that probability to detect high severity vulnerability
reaches 96.85%.
So automated scanning represents data for an average Internet site
and black and white box methods results refer to interactive
corporate web applications.
P. 1 Probability to detect vulnerabilities of different risk degree
The most prevalent vulnerabilities are Cross-Site Scripting, Information Leakage, SQL Injection and Predictable Resource Location (P. 2, P. 3). As a rule, Cross-Site Scripting and SQL Injection vulnerabilities appears due to system design errors, Information Leakage and Predictable Resource Location are often connected with improper system administration (for example, weak access control).
P. 2 The most prevalent vulnerabilities
P. 3 Vulnerability frequency by types
While detailed system analysis with BlackBox and WhiteBox methods appreciable percentage of sites are vulnerable to Content Spoofing, Insufficient Authorization and Insufficient Authentication (P. 4, P. 5). With this approach to security assessment the probability to detect SQL Injection reaches 25%.
P. 4 The most prevalent vulnerabilities (BlackBox & WhiteBox)
P. 5 Vulnerability frequency by types (BlackBox & WhiteBox)
In terms of Web Application Consortium Threat Classification version 1 classes (T. 1 and P. 6) the most prevalent classes of vulnerabilities are Client-side Attacks, Information Disclosure and Command Execution. The detailed analysis shows the popularity of Authentication and Authorization classes (P. 7).
T. 1 The probability distribution of vulnerabilities detection according to WASC TCv1 classes
| | % ALL | % Scans | % Black & WhiteBox
|
| Authentication | 1.17% | 0.02% | 20.82%
|
| Authorization | 1.28% | 0.07% | 19.01%
|
| Client-side Attacks | 33.13% | 31.17% | 69.37%
|
| Command Execution | 8.15% | 7.32% | 27.85%
|
| Information Disclosure | 31.78% | 30.42% | 56.54%
|
| Logical Attacks | 0.90% | 0.20% | 13.92%
|
P. 6 The probability distribution of vulnerabilities detection according to WASC TCv1 classes
P. 7 The probability distribution of vulnerabilities detection according to WASC TCv1 classes (BlackBox & WhiteBox)
The Comparison of security assessment methods
While compared automated scanning with detailed Blackbox and Whitebox analysis methods, it is evidently clear that detailed analysis is much more effective to detect Authorization and Authentication class vulnerabilities and logic flaws (T. 2, P. 8).
T. 2 Automated scanning vs Blackbox and Whitebox analisys (% Sites)
| Threat Classification |
Scans vs Black & WhiteBox |
| Content Spoofing |
18.30% |
| Insufficient Authorization |
14.15% |
Insufficient Authentication |
12.95% |
| SQL Injection |
8.68% |
P. 8 The difference in probability of vulnerabilities detection using different methods
As mentioned above (P 1), the probability to detect high risk degree vulnerability using detailed analysis is 12.5 times higher than using automated scanning.
According to the number of vulnerabilities detected for a site (T. 3 and P. 9) the detailed analysis allows to detect on average 9 high risk degree vulnerabilities per site while automated scanning allows to detect only 2.3 vulnerabilities of this rank.
T. 3 Number of vulnerabilities per site
| | All | Scans | Black&WhiteBox
|
| Low | 3.15 | 2.96 | 1.11
|
| Med | 2.35 | 2.04 | 2.65
|
| High | 4.22 | 2.33 | 8.91
|
| All | 2.12 | 1.61 | 13.11
|
P. 9 Number of vulnerabilities per site
Additional notes
Web Application Security Consortium Threat Classification version 1 was used in this research. Therefore some types of vulnerabilities are not included into the overall results. We plan to use WASC TC version 2 in future.
The most prevalent vulnerability Cross-Site Request Forgery in this statistics is not on top because it is difficult to detect in automatically and because a lot of experts take its existence for granted.
Vulnerabilities which existence depends on platform are also not included into the statistics (for example, buffer overflow in Apache).
Contributors
WASC would like to thank the following organizations for making this initiative possible. Each organization is responsible for contributing sanitized data from web application security projects which was then combined to produce aggregated statistics.
Statistics
Overall Data
T. 4 General statistics
| Threat Classification | N of Vulns | N of Sites | % Vulns | % Sites
|
| Abuse of Functionality | 169 | 99 | 0.24% | 0.30%
|
| Brute Force | 291 | 125 | 0.42% | 0.38%
|
| Buffer Overflow | 171 | 19 | 0.25% | 0.06%
|
| Content Spoofing | 1399 | 213 | 2.01% | 0.65%
|
| Credential/Session Prediction | 79 | 46 | 0.11% | 0.14%
|
| Cross-site request forgery | 993 | 126 | 1.43% | 0.39%
|
| Cross-site Scripting | 28769 | 10297 | 41.41% | 31.47%
|
| Denial of Service | 55 | 44 | 0.08% | 0.13%
|
| Directory Indexing | 281 | 87 | 0.40% | 0.27%
|
| Fingerprinting | 120 | 60 | 0.17% | 0.18%
|
| Format String Attack | 104 | 12 | 0.15% | 0.04%
|
| HTTP Response Splitting | 749 | 265 | 1.08% | 0.81%
|
| Information Leakage | 22156 | 7614 | 31.89% | 23.27%
|
| Insufficient Anti-automation | 288 | 115 | 0.41% | 0.35%
|
| Insufficient Authentication | 356 | 229 | 0.51% | 0.70%
|
| Insufficient Authorization | 343 | 218 | 0.49% | 0.67%
|
| Insufficient Process Validation | 117 | 38 | 0.17% | 0.12%
|
| Insufficient Session Expiration | 200 | 91 | 0.29% | 0.28%
|
| LDAP Injection | 21 | 11 | 0.03% | 0.03%
|
| OS Commanding | 25 | 9 | 0.04% | 0.03%
|
| Path Traversal | 178 | 145 | 0.26% | 0.44%
|
| Predictable Resource Location | 5331 | 3349 | 7.67% | 10.24%
|
| Session Fixation | 183 | 65 | 0.26% | 0.20%
|
| SQL Injection | 6420 | 2567 | 9.24% | 7.85%
|
| SSI Injection | 185 | 40 | 0.27% | 0.12%
|
| URL Redirectors | 210 | 195 | 0.30% | 0.60%
|
| Weak Password Recovery Validation | 164 | 31 | 0.24% | 0.09%
|
| WSDL Exposure | 60 | 20 | 0.09% | 0.06%
|
| XPath Injection | 59 | 16 | 0.08% | 0.05%
|
| Total | 69476 | 32717 | |
|
T. 5 Vulnerabilities distribution by risk
| Threat rank | N of Vulns | N of Sites | % Vulns | % Sites
|
| Low | 24433 | 7760 | 35.17% | 23.72%
|
| Med | 29575 | 12596 | 42.57% | 38.50%
|
| High | 13765 | 3263 | 19.81% | 9.97%
|
T. 6 Vulnerabilities distribution by WASC TCv1 classes
| WASC Classes | N of Vulns | N of Sites | % of Vulns | % Sites
|
| Authentication | 811 | 384 | 1.17% | 1.17%
|
| Authorization | 805 | 418 | 1.16% | 1.28%
|
| Client-side Attacks | 32120 | 10840 | 46.23% | 33.13%
|
| Command Execution | 6985 | 2665 | 10.05% | 8.15%
|
| Information Disclosure | 28126 | 10398 | 40.48% | 31.78%
|
| Logical Attacks | 629 | 295 | 0.91% | 0.90%
|
Automatic scans
T. 7 General statistics
| Threat Classification | N of Vulns | N of Sites | % Vulns | % Sites
|
| Abuse of Functionality | 5 | 3 | 0.01% | 0.01%
|
| Brute Force | 3 | 3 | 0.01% | 0.01%
|
| Buffer Overflow | | | 0.00% | 0.00%
|
| Content Spoofing | 33 | 21 | 0.06% | 0.07%
|
| Credential/Session Prediction | 4 | 4 | 0.01% | 0.01%
|
| Cross-site request forgery | 87 | 53 | 0.17% | 0.17%
|
| Cross-site Scripting | 19171 | 9651 | 37.29% | 30.26%
|
| Denial of Service | 30 | 22 | 0.06% | 0.07%
|
| Directory Indexing | 91 | 12 | 0.18% | 0.04%
|
| Fingerprinting | | | 0.00% | 0.00%
|
| Format String Attack | | | 0.00% | 0.00%
|
| HTTP Response Splitting | 182 | 161 | 0.35% | 0.50%
|
| Information Leakage | 21157 | 7115 | 41.16% | 22.31%
|
| Insufficient Anti-automation | 37 | 38 | 0.07% | 0.12%
|
| Insufficient Authentication | 2 | 2 | 0.00% | 0.01%
|
| Insufficient Authorization | 6 | 11 | 0.01% | 0.03%
|
| Insufficient Process Validation | | | 0.00% | 0.00%
|
| Insufficient Session Expiration | 3 | 3 | 0.01% | 0.01%
|
| LDAP Injection | | | 0.00% | 0.00%
|
| OS Commanding | 19 | 3 | 0.04% | 0.01%
|
| Path Traversal | 118 | 116 | 0.23% | 0.36%
|
| Predictable Resource Location | 4772 | 3213 | 9.28% | 10.07%
|
| Session Fixation | 3 | 3 | 0.01% | 0.01%
|
| SQL Injection | 5301 | 2298 | 10.31% | 7.21%
|
| SSI Injection | 180 | 37 | 0.35% | 0.12%
|
| URL Redirectors | 195 | 182 | 0.38% | 0.57%
|
| Weak Password Recovery Validation | 1 | 1 | 0.00% | 0.00%
|
| WSDL Exposure | | | 0.00% | 0.00%
|
| XPath Injection | 4 | 1 | 0.01% | 0.00%
|
| Total | 51404 | 31891 | |
|
T. 8 Vulnerabilities distribution by risk
| Threat rank | N of Vulns | N of Sites | % Vulns | % Sites
|
| Low | 21736 | 7352 | 42.28% | 23.05%
|
| Med | 24452 | 12012 | 47.57% | 37.67%
|
| High | 5736 | 2463 | 11.16% | 7.72%
|
T. 9 Vulnerabilities distribution by WASC TCv1 classes
| WASC Classes | N of Vulns | N of Sites | % of Vulns | % Sites
|
| Authentication | 6 | 6 | 0.01% | 0.02%
|
| Authorization | 16 | 21 | 0.03% | 0.07%
|
| Client-side Attacks | 19668 | 9941 | 38.26% | 31.17%
|
| Command Execution | 5504 | 2336 | 10.71% | 7.32%
|
| Information Disclosure | 26138 | 9701 | 50.85% | 30.42%
|
| Logical Attacks | 72 | 63 | 0.14% | 0.20%
|
Black Box & White Box
T. 10 General statistics
| Threat Classification | N of Vulns | N of Sites | % Vulns | % Sites
|
| Abuse of Functionality | 114 | 66 | 1.05% | 7.99%
|
| Brute Force | 148 | 66 | 1.37% | 7.99%
|
| Buffer Overflow | 1 | 1 | 0.01% | 0.12%
|
| Content Spoofing | 646 | 152 | 5.96% | 18.40%
|
| Credential/Session Prediction | 25 | 10 | 0.23% | 1.21%
|
| Cross-site request forgery | 74 | 13 | 0.68% | 1.57%
|
| Cross-site Scripting | 6418 | 480 | 59.26% | 58.11%
|
| Denial of Service | 25 | 22 | 0.23% | 2.66%
|
| Directory Indexing | 60 | 39 | 0.55% | 4.72%
|
| Fingerprinting | 80 | 51 | 0.74% | 6.17%
|
| Format String Attack | 4 | 2 | 0.04% | 0.24%
|
| HTTP Response Splitting | 447 | 64 | 4.13% | 7.75%
|
| Information Leakage | 639 | 339 | 5.90% | 41.04%
|
| Insufficient Anti-automation | 16 | 14 | 0.15% | 1.69%
|
| Insufficient Authentication | 204 | 107 | 1.88% | 12.95%
|
| Insufficient Authorization | 187 | 117 | 1.73% | 14.16%
|
| Insufficient Process Validation | 77 | 18 | 0.71% | 2.18%
|
| Insufficient Session Expiration | 17 | 16 | 0.16% | 1.94%
|
| LDAP Injection | 1 | 1 | 0.01% | 0.12%
|
| OS Commanding | 6 | 6 | 0.06% | 0.73%
|
| Path Traversal | 60 | 29 | 0.55% | 3.51%
|
| Predictable Resource Location | 499 | 121 | 4.61% | 14.65%
|
| Session Fixation | 120 | 22 | 1.11% | 2.66%
|
| SQL Injection | 879 | 209 | 8.12% | 25.30%
|
| SSI Injection | 5 | 3 | 0.05% | 0.36%
|
| URL Redirectors | 11 | 11 | 0.10% | 1.33%
|
| Weak Password Recovery Validation | 13 | 10 | 0.12% | 1.21%
|
| WSDL Exposure | 0 | 0 | 0.00% | 0.00%
|
| XPath Injection | 55 | 15 | 0.51% | 1.82%
|
| Total | 10831 | 826 | |
|
T. 11 Vulnerabilities distribution by risk
| Threat rank | N of Vulns | N of Sites | % Vulns | % Sites
|
| Low | 452 | 408 | 4.17% | 49.39%
|
| Med | 1549 | 584 | 14.30% | 70.70%
|
| High | 7127 | 800 | 65.80% | 96.85%
|
T. 12 Vulnerabilities distribution by WASC TCv1 classes
| WASC Classes | N of Vulns | N of Sites | % of Vulns | WASC Classes
|
| Authentication | 365 | 172 | 3.37% | 20.82%
|
| Authorization | 349 | 157 | 3.22% | 19.01%
|
| Client-side Attacks | 7596 | 573 | 70.13% | 69.37%
|
| Command Execution | 951 | 230 | 8.78% | 27.85%
|
| Information Disclosure | 1338 | 467 | 12.35% | 56.54%
|
| Logical Attacks | 232 | 115 | 2.14% | 13.92%
|
First Round
This initial round of statistics was compiled from data provided by four vendors - Whitehat Security, SPI Dynamics, Positive Technologies and Cenzic in 2006. The detailed information can be found here.
Participation
If you represent an organization that performs vulnerability assessments
on websites, particular in those in custom web applications, through a
manual or automated process and would like to participate please let us
know. Once statistics are compiled, a report will be distributed, and
all contributors will receive a logo on the project pages as well as on
other deliverables in appreciate of their contribution.
Please contact
Sergey Gordeychik.
Statistics will be collected once per year one month after December 31.
